Tutor XG

Static rope

The “next generation”, Tutor XG, replaces Tutor HST. This static rope is very robust and abrasion resistant.

Specifications

Core: Nylon
Cover: Nylon
Standard: EN 1891 A
Braid:

  • Diameter 10 mm: 32
  • Diameters 10,5-12mm: 40

Made in

Color Images

  • Tutor XG

    White/Red

    10 mm

  • Tutor XG

    Orange/Black

    10 mm

  • Tutor XG

    White/Red

    10,5 mm

  • Tutor XG

    Orange/Black

    10,5 mm

  • Tutor XG

    Red/Black

    10,5 mm

  • Tutor XG

    Blue/Black

    10,5 mm

  • Tutor XG

    Black

    10,5 mm

  • Tutor XG

    White/Red

    11 mm

  • Tutor XG

    Orange/Black

    11 mm

  • Tutor XG

    Red/Black

    11 mm

  • Tutor XG

    Blue/Black

    11 mm

  • Tutor XG

    Black

    11 mm

  • Tutor XG

    Red/Yellow

    12 mm


Due to its higher cover proportion and the 40-plait braided cover, Tutor XG is very robust and also features particularly high breaking forces in the figure eight hitch (especially the 11mm diameter). The closely braided thick 40-plait cover of polyamide offers protects the core from ingress of dirt and offers high abrasion resistance. Tutor XG is certified to EN 1891 A, and in selected systems also to 353-2.

Features

  • Very robust due to high cover proportion
  • High abrasion resistance due to 40-plait braided cover
  • Extremely high breaking force of 11mm in figure eight hitch
Diameter
[mm]
Diameter
[inch]
Weight
[g/m]
Weight
[lbs/100']
Shrinkage
[%]
Elongation at 50-150kg
[%]
Min. breaking strength, free length
[daN]
Min. breaking strength, free length
[lbf]
Min. breaking strength, with figur 8 knot
[daN]
Min. breaking strength, with figur 8 knot
[lbf]
Cover
[%]
10 7/16 61 4.10 3 3 2,600 5,845 1,600 3,595 40
10.50 13/32 70.50 4.70 3 3 3,200 7,190 1,800 4,040 36
11 7/16 76 5.10 4 3 3,400 7,640 2,000 4,495 41
12 1/2 87.90 5.90 4 3 3,800 8,540 2,100 4,720 35
Typing errors and technical changes reserved. The data are typical values without warranty or guarantee. For questions we are always at your disposal.
