PLATINUM® Protect XG PES/PA

Static ropes

With PLATINUM® Protect XG PES/PA, TEUFELBERGER has taken its PLATINUM® range to the next level. This rope is perfectly suited for working at great heights and in rough terrain.

Specifications

Core: Nylon
Cover: Polyester
Standard: EN 1891 A, NFPA 2500 (1983)
Braid: 32



Made in
Color Images
  • Platinum® Protect XG PES/PA

    Red/White

    11 mm

  • Platinum® Protect XG PES/PA

    White/Red

    11 mm

Like in all other ropes with PLATINUM® technology, the core and cover are interconnected at regular intervals. In the PLATINUM® Protect XG PES/PA, however, the binding yarn also changes its direction at each connecting point. This makes the rope steadier in access and features reduced kinking especially in case of long abseiling distances. Due to the low stretch, the good UV resistance as well as the high abrasion resistance of the polyester cover, PLATINUM® Protect XG PES/PA is perfectly suited for working at great heights and in rough terrain.

Features

  • Low stretch
  • Reduced kinking in case of long abseiling distances
  • Excellent UV resistance
Diameter
[mm]
Diameter
[inch]
Weight
[g/m]
Weight
[lbf/100]
Shrinkage
[%]
Elongation 50-150kg
[%]
Min. breaking strength, free length
[daN]
Min. breaking strength, free length
[lbf]
Min. breaking strength, with figur 8 knot
[daN]
Min. breaking strength, with figur 8 knot
[lbf]
Min. Bruchkraft, Vernäht
[daN]
Min. breaking strength, sewn
[lbf]
Cover
[%]
11 7/16 86,0 5,78 3 3 3.400 7 640 1.700 3.820 47,0
Typing errors and technical changes reserved. The data are typical values without warranty or guarantee. For questions we are always at your disposal.
