arborWINCH

Winch rope for tree care

Our arborWINCH rope is ideally suited for winch applications in tree care and certified to the Machinery Directive 2006/42/EC.

Specifications

Lengths: 600 m, 50 m
Standard: Machinery Directive 2006/42/EC as amended
Core: Dyneema®
Cover: polyester/polyester
Plait number: 32

Made in

Color Images

  • Yellow/Orange

    12 mm

The arborWINCH from TEUFELBERGER has been specifically developed for winch applications in tree care. It is thus ideally suited for use in forestry winches and for logging.

This 12-mm winch rope is certified to the Machinery Directive 2006/42/EC as amended.

It consists of a braided Dyneema® SK78 core. Therefore, free lengths of this rope are able to support loads of up to 7.000 daN. Its intermediate cover made of polyester staple fibers effectively prevents any core/cover displacement.

The following features make our arborWINCH perfectly suited for tree care work:

  • Very high breaking load
  • Intermediate cover preventing any core/cover displacement
  • Quality tested to the Machinery Directive

The winch rope is available in the signal colors red and yellow which makes it the ideal choice for work in forests.

Diameter
[mm]
Diameter
[inch]
Min. breaking strength, free length
[daN]
Min. breaking strength, free length
[lbf]
Min. breaking strength, spliced
[daN]
Min. breaking strength, spliced
[lbf]
Weight
[g/m]
Weight
[lbs/100]
12 1/2 7,000 15,730 5,700 12,810 98 6.60
Typing errors and technical changes reserved. The data are typical values without warranty or guarantee. For questions we are always at your disposal.
